HL190 49 Ton Excavator Hydraulic Breaker Rod Hydraulic Hammer Pile Large

HL190 Hydraulic Breaker Rod Hydraulic Hammer Pile Large Hydraulic Breaker


HL hydraulic breaker has set up machines such as MCT (universal machine tool center), CNC (numerical control machine tool) and large-scale grinding machine for breaker after several investment in facilities to realize automatic manufacturing process and stable quality. In particular, the inner side of the cylinder and the valve is processed by a large-scale inner diameter grinder specially for the breaker to ensure the accuracy of the centrality, and the special super processing and inner diameter grinding operations are used to improve the surface fineness and product perfection.

Model and selection:

1) The number in the hydraulic hammer model may indie the weight of the excavator or the bucket capacity, or the weight of the hydraulic hammer, or the diameter of the drill rod, or the impact energy of the hydraulic hammer. In most cases, there is no one-to-one correspondence between a number and its meaning, and it is often a range of numbers. And sometimes the parameters of the hydraulic hammer have changed, but the model remains the same, which makes the meaning of the model number even more ambiguous. What's more, the data does not match the actual data, so users should pay more attention.

2) The matching of hydraulic hammer and excavator, for excavator users, the main consideration is the matching of weight, but also to verify the matching of power. For other load-bearing machines, power matching and weight matching are equally important. It is also very reliable to select hydraulic hammer according to the experience of other users.

project	unit	HL190
total length	mm	3253
working weight	kg	4888
	ib	10755
work pressure	kgf/cm2	180-220
	psi	2559-3182
oil quantity	l/min	220-260
	gpm	58.1-68.6
Strike frequency	bpm	210-300
Drill rod diameter	mm	190
	inch	7.27
Drill rod length	mm	1800
	inch	70.76
Drill rod weight	kg	340
Tubing size	mm	32
	inch	PF1-1/4"
Suitable for excavators	ton	37-49
	m3	1.4-2.0

Specifiion

item	value
Showroom Loion	None
Video outgoing-inspection	Provided
Machinery Test Report	Provided
Marketing Type	Hot Product 2022
Place of Origin	China
province	Guangdong
brand	HL
Warranty	1 Year
new or old	New
use	construction work
weight	4888kg
Suitable Excavator(ton)	37-49ton
Core Components	mainbody
Brand	HL
Payment	T/T;MoneyGram;Western Union;D/P;D/A;T/T
Delivery	5-15 Days
Process	forging
Local Service Loion:	None
Warranty of core components	1 years
After Warranty Service	Video technical support, Online support
After-sales Service Provided	Video technical support, Online support



Guangzhou Hengli Construction Machinery was established in 2011 as a diversified professional machinery parts company integrating innovation, sales and service. With a high-quality professional technical team, a complete sales and service network, an independent innovation of high-strength, high wear-resistant, high-performance materials and an unique precision forging process, our product quality is at the leading level in the industry. And according to international standards, we have established a set of modern quality management system. Our products are suitable for large coal mines, iron ore mines, copper mines, oil sands mines and other industrial mines. We have become a long-term partner of many OEM machines in the world. Our products sell well all over the world, and their performance is well received and recognized by our customers. We have a physical store as well as a marketing and after-sales operation center in the central area of Guangzhou, Guangdong Province, with 500 and 800 square meters respectively. Our main products include: forged bucket teeth, forged bucket adapters, bucket tooth pins, DDR brand high wear-resistant bucket pins, bucket bushings, screws, gaskets, etc. We are specialized in selling chassis parts, engine parts, hydraulic parts, gear parts, vulnerable parts, hammer parts, hydraulic cylinders, filter series and other construction machinery parts. We warmly welcome domestic and foreign customers to cooperate and create a better future together.


Applicable models
Komatsu	PC40	Kobelco	SK55
	PC55/56		SK60/SK75
	PC60/PC60-5		SK60-8
	PC90		SK100/SK140
	PC100/PC120		SK200/SK230
	PC200-3		SK220
	PC200-5/7/SY215		SK270
	PC200		SK330/SK350/SK360
	PC240-8		SK330-8(超8)
	PC300-5/PC360/-7		SK450
	PC360-8		SK850
	PC400	Sumitomo	SH60
	PC600-5		SH120
	PC650-8		SH120A3
	PC750/800		SH200/280/210/240
	PC1250		SH220
Carter	E55/E305.5/E306		SH240
	E70B/E307		SH300/A3
	E120B/312		SH350
	E200B/E320		SH360
	E324		SH400/460
	E325/325		SH450
	E330	modern	R55
	E345		R60/Ishikawa island60/LG60/-5
	E365D		R80
	E375/385/390		R130/R150-9
Hitachi	ZAX55/EX55/ZAX60		R200/R210
	EX60-2		R225-7
	ZAX70		R265-7/R265
	EX100		R290
	EX200-2		R305/
	EAX200/		R450
	ZAX200-5G		R485505520
	EX300-1		R974
	EX300-5	Yuchai	CY35
	EX360-5G		YC60
	EX400		CY85
	ZAX450		CY18
	EX550/ZAX650		YC135
	ZAX670	Liebherr	LIEBHERR914/924/916
	EX800		LIEBHERR934
	ZAX870		R944
Doosan	DH55		JONGYANG200-3/5/ZY230
	DX60		JONGYANG300
	DH80		SUNWARD50
	DX75/80		SUNWARD70/60
	DX140/150		KUBOTA50/60/161
	DH130/150		KUBOTA85/185
	DH220		TAKEUCHI150/160
	DX200/DX260		TAKEUCHI175
	DH258		TAKEUCHI185
	DX300		RAY WALTER60
	DH280/300		RAY WALTER85
	DH360/DH420		YANMAN55
	DH370-9		YANMAN75
	DX380	Liugong	LIUGONG906/short
	DX480/500		LIUGONG906E
	DH500		LIUGONG908
Volvo	EC55B		LIUGONG908E/long
	EC80		LIUGONG915
	EC140		LIUGONG925
	EC210/240		LIUGONG933/936
	EC290		LIUGONG948/950
	VOL290		LIUGONG970
	EC360	三一	三一65
	EC460/480		ZY200
	VOL700		ZY300
Case	CX55		XCMG280
	CX75		Jin Gong924
	CX135		XG806
	CX240		LG85/E6085
	CX350		Ishikawa island100
JCB	JCB220(280x80)		GJ100
	JCB220(280x90)
	JCB240
	JCB290
	JCB360/370
	HD250
	HD450
	HD700/820/1023
	HD1250/HD1430
	ZOOMLION280
	ZOOMLION230
	XCMG700

Product Description







FAQ:

1. Are you a trader or a manufacturer?

We are a specialized machinery parts manufacturing company integrating product development, production, sales and service.

2. How to determine the parts are suitable for my excavator?

Please provide us with the correct model/machine serial number/any part number, or measure the part size, drawing.

3. What is your minimum order quantity?

There is no limit to this, it depends on the number of products you buy.

4. What are your advantages in the machinery manufacturing industry?

We have a strong spot inventory, fast delivery time, adopt the latest production technology and craftsmanship, high-quality products, and the best customer service.

5. How is the packaging of the goods?

Standard export packaging, wooden boxes, pallets, or according to customer requirements.

6. How long is the delivery time?

For products in stock, the delivery time is 2-7 days after the order is confirmed, and 15-25 days for other products. The specific need to communie and negotiate.

7. Can we customize products with our brand?

Of course, we welcome cooperation to customize OEM/ODM product services, which can be completed from design, production, packaging, and logistics.

8. What kind of payment methods do you accept?

We usually accept T/T, L/C or Western Union. Other payment methods can also be negotiated.

9. Can you provide after-sales service?

Of course, we have professional after-sales technicians to help you solve the problems you encounter.

10. What other services can you provide?

10-1. Warranty for one year, free replacement for damage with abnormal wear.

10-2. Provide technical support to customers.

10-3. Help you develop the market.

10-4. Exclusive agent VIP treatment.
